Video and Audio

IP Video Input

4-ch
Up to 6 MP resolution

Incoming Bandwidth

40 Mbps

Outgoing Bandwidth

60 Mbps

HDMI Output

1-ch, 1920 × 1080p/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60Hz, 1280 × 720/60 Hz

VGA Output

1-ch, 1920 × 1080p/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz

Video Output Mode

HDMI/VGA simultaneous output

Decoding

Decoding Format

H.265+/H.265/ H.264+/H.264

Recording Resolution

6 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF

Synchronous playback

4-ch

Decoding Capability

4-ch@1080p (30 fps) or 2-ch@4 MP (30 fps) or 1-ch@6 MP (30 fps)

Stream Type

Video, Video & Audio

Network

Remote Connection

16

Network Protocol

TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP™

Network Interface

1, RJ-45 10/100 Mbps self-adaptive Ethernet interface

PoE

Interface

4, RJ-45 10/100 Mbps self-adaptive Ethernet interface

Power

≤ 36 W

Standard

IEEE 802.3 af/at

Auxiliary Interface

SATA

1 SATA interface

Capacity

Up to 6 TB capacity for each disk

Alarm In/Out

N/A

USB Interface

Rear panel: 2 × USB 2.0

General

Power Supply

48 VDC, 1 A

Consumption

≤ 10 W (without HDD and PoE off)

Working Temperature

-10 °C to 55 °C (14 °F to 131 °F)

Working Humidity

10% to 90%

Dimension (W × D × H)

265 × 225 × 48 mm (10.4″ × 8.9″ × 1.9″)

Weight

≤ 1 kg (without HDD, 2.2 lb.)
